Readability (mg) : 0.01
Maximun capacity : 120
Readability (at 5% load) (mg)
Standard deviation of load values, tolerancing : 0.015
Standard deviation of load values, typical value : 0.025
Readability (at aprox 100% load)
Standard deviation of load values, tolerancing : 0.002
Standard deviation of load values, typical value : 0.03
Linearity deviation (mg)
Toleramce : 0.02
Typical value : 0.03
Deviation when load if off-center positions according OIMLR76 (µg)
Test weight : 100
Tolerance (mg) : 0.04
Typical value (mg) : 0.06
Sensitivity drift between (+10C-30C) ppm/K : 8
Tare max capacity <100% of max capacity
Accuracy class (according to directive 2014I31IEU) : -
Verification scale interval (e) (according to directive 2014I31IEU) : 0.1
Min load (according to directive 2014I31IEU) (mg) : 1
Min initial weighing according to USP (United States Pharmacopeia chap.41)
Optimum min initial weighing (mg) : 0.82
Typical min initial weighing (mg) : 1.3
Typical stabilization time (s) : 3
Typical measurement time (s) : 5
Recommended calibration weight
External calibrated test weight (g) : 100
Accuracy class (in accordance with OIMLR111-1) : E1
Temp in operation : 18C-23C
Warm-up temp fluctuation : ≤1C/H
Relative humidity : 50%-75%
Power supply : 100V-240V AC Freq : 50/60Hz Current : 1.0A-0.5A
Dimension (mm) : 240x430x380
Weighing pan size (mm) : ɸ85*85
Weight chamber height (mm) : 248
Net weight approx. (kg) : 9.86
