Readability (µg) : 1
Maximun capacity : 31
Readability (at 5% load) (µg)
Standard deviation of load values, tolerancing : 2
Standard deviation of load values, typical value : 2.5
Readability (at aprox 100% load)
Standard deviation of load values, tolerancing : 2.5
Standard deviation of load values, typical value : 5
Linearity deviation (µg)
Toleramce : 2
Typical value : 5
Deviation when load if off-center positions according OIMLR76 (µg)
Test weight : 20
Tolerance : 2
Typical value : 5
Sensitivity drift between (+10C-30C) ppm/K : 5
Tare max capacity <100% of max capacity
Accuracy class (according to directive 2014I31IEU) : -
Verification scale interval (e) (according to directive 2014I31IEU) : 10
Min load (according to directive 2014I31IEU) (mg) : 1
Min initial weighing according to USP (United States Pharmacopeia chap.41)
Optimum min initial weighing (mg) : 0.82
Typical min initial weighing (mg) : 1.3
Typical stabilization time (s) : 8
Typical measurement time (s) : 12
Recommended calibration weight
External calibrated test weight (g) : 20
Accuracy class (in accordance with OIMLR111-1) : E1
Temp in operation : 18C-23C
Warm-up temp fluctuation : ≤1C/H
Relative humidity : 50%-75%
Power supply : 100V-240V AC Freq : 50/60Hz Current : 1.0A-0.5A
Dimension (mm) : 90x295x150
Weighing pan size (mm) : ɸ30
Net weight approx. (kg) : 4.7
