Spesifikasi:
Model:
Basic: DW-FD29A DW-FD50A DW-FD80A DW-FD100A
Drying: DW-FD50R DW-FD80R DW-FD100R
Difference:
DW-FD-A: Fully automatic
DW-FD-E+semi automatic drying function, if need automatic drying need to add 530USD
Capacity(L): 29 50 80 100
Dimension(L*W*H)(mm): 580x490x960 580x490x 1085 730x625x1100 730x625x1200
Chamber dimension(Dia*H)(mm): Φ320×378 Φ320 x725 Φ400 x700 Φ400 x 800
Power requirements: 220V±10% 16A 50HZ/60HZ 220V±10% 32A 50HZ/60HZ
Rated power(W): 2600W 2600W 4600W 4600W
Sus304 basket size(pcs): (Φ298×260)x1 (Φ298×195)x3 (Φ360×275)x2 (Φ360×215)x3
Chamber material; SUS304 stainless steel
Sterilization temperature: 105℃~135℃
Sterilization time range: 1～300min
Pressure gauge range: -0.1MPa～0.5MPa
Pulse times: 0～9 times (E/R only)
Exhaust temperature range: 73℃~104℃(E/R only, liquid mode)105℃~130℃(Solid mode)
Safety valve set pressure: 0.29MPa
Drying: Drying temperature:80℃~160℃ Drying time:1～300 min
Sterilization mode: Solid mode Liquid mode Sterilization+ drying (R only)
Controller: Microcomputer control system
Safety device: Lid closing checking, over temperature protection system, dry scorch protection,
overpressure protection, safety valve, over current/short circuit/electric leakage protection, scald protection, automatic failure-inspection system
