Range Battery Resistance : 3 mΩ, 30 mΩ, 300 mΩ, 3000 mΩ
Resolution Battery Resistance : 0.001 mΩ, 0.01 mΩ, 0.1 mΩ, 1 mΩ
Accuracy : 1% + 8, 0.8% + 6
Range V DC : 6 V, 60 V, 600 V, 1000 V
Resolution V DC : 0.001 V, 0.01 V, 0.1 V, 1 V
Accuracy V DC : 0.09% + 5
Range Vac (45 Hz to 500 Hz with 800 Hz filter) : 600 V
Resolusi : 0.1 V
Accuracy : 2 % + 10
Range Frequency (displayed with Vac and Aac) : 500 Hz
Resolution : 0.1 Hz
Accuracy : 0.5 % + 8
Range AC voltage ripple (20 KHz Max) : 600 mV, 6000 mV
Resolution : 0.1 mV, 1 mV
Accuracy : 3 % + 20, 3 % + 10
Range Adc/Aac (with accessory Fluke i410) : 400 A
Resolution : 1 A
Accuracy : 3.5 % + 2
Range Temperature : 0 °C to 60 °C
Resolution : 1 °C
Accuracy : 2 °C
Meter mode : 999 records for each measurement position with time stamp
Sequence mode : Up to 100 profiles and 100 profile templates (Each profile stores up to 450 batteries) with time stamp
Operating temperature : 0 °C to 40 °C
Storage temperature : -20 °C to 50 °C
Lithium-ion battery charging temperature : 0 °C to 40 °C
Operating altitude : Sea level to 2000 meters
Storage altitude : Sea level to 12,000 meters
IP rating : IP40
Radio : FCC Class A
Vibration requirements : MIL-PRF-28800F: Class 2
Drop test requirements : 1 meter
Temperature coefficients : Add 0.1 x specified accuracy for each degree C above 28 °C or below 18 °C
Safety compliance : 600 V CAT III
EMC : IEC 61326
ROHS : China, Europe
Protection Class 2 : Pollution Degree II
Screen dimensions : 7.7 cm x 5.6 cm (3 in x 2.2 in)
Interface : USB mini
Size (HxWxD) : 22 cm x 10.3 cm x 5.8 cm (9 in x 4 in x 2 in)
Weight : 850 g (1.9 lb)
