Resistance measurement range :
3 mΩ (max. display 3.100 mΩ, resolution 1 μΩ) to 3 Ω (max. display 3.100 Ω, resolution 1 mΩ), 4 ranges
Accuracy : ±0.8 % rdg. ±6 dgt. (3 mΩ range: ±1.0 % rdg. ±8 dgt.)
Testing source frequency : 1 kHz ±30 Hz, With function for avoiding noise
Frequency enabled : 1 kHz ±80 Hz, Testing current: 160 mA (3m/30 mΩ range), 16 mA (300 mΩ range), 1.6 mA (3 Ω range), Open terminal Voltage: 5 V peak
Voltage measurement range : ± 6 V (max. display ±6.000 V, resolution: 1 mV) to ± 60 V (max. display ±60.00 V, resolution: 10 mV), 2 ranges, Accuracy: ±0.08 % rdg. ±6 dgt
Absolute max. input voltage : 60 V DC max. (No AC input)
Display update rate : Approx. 3 times/s
Comparator functions : Resistance warning limit / failure limit, and voltage warning limit setting; Number of comparator setting: 200 sets, Beeper sound, PASS/WARNING or FAIL
Data storage : Max. storable data: 6000 sets. (Saved items: Date, time, resistance value, voltage value, temperature, comparator setting values, and comparator judgement.)
Communication interface :
Via USB (forward the data to the PC, bundled software)
Built-in Bluetooth® 4.0 LE, supports tablets and smart phones with iOS 10 or Android™4.3 or later
GENNECT Cross (Freeware): Display list of measured values, generate reports, or display the trend (on the PC only)
Other functions : Temperature measurement (-10.0 to 60.0 °C), Zero-adjustment, Hold, Auto-hold, Auto-memory, Auto-power-save, Clock
Power supply : LR6 (AA) Alkaline dry battery ×8, Continuous operating time: 8.5 hr
Standard leads : L2020
Dimensions : 199 mm (7.83 in)W × 132 mm (5.20 in)H × 60.6 mm (2.39 in)D (with protector), 947 g (33.4 oz) (including batteries and protector)
