Spesifikasi:
Model:
SS/50/65/3 SS/100/65/3 SS/200/65/3 SS/300/65/3 SS/500/65/3 SS/1000/65/3
Volume : 50L 100L 200L 300L 500L 1000L
Internal Dimensions W×H×Dmm:
350*400*350 450*500*450 650*460*670 960*460*670 960*650*800 1100*900*1000
External dimensions W×H×D mm:
1330*2010*1524 1450*2050*1650 1650*2050*1900 1980*2050*2000
1980*2250*2400 2050*2250*2400
High temperature range : +60 to +200°C
Temperature Heating Time: Ambient temperature to +200°C within 15 minutes
Low temperature range: A: –40 to 0°C, B: –55 to 0°C, C: –65 to 0°C
Cooling Time: Ambient temperature to -75°C
within 40 minutes within 45 minutes within 50 minutes
Test Area Load-bearing Capacity : 30KG 50KG 100KG
System: Experiment with damper switching
