Throughput : 60 Samples/ hour
Analysis Channel : Dual-Channel for counting
Innovative Technology : Automatic floating discriminators, Plus baseline tracking technology, Waveform discrimination technology, Digital Sheath-Flow technology
Principles :
Tri-angle laser, flow cytometry, chemical dye method for 5-part differential analysis and WBC counting
Electrical impedance method for RBS nad PLT counting
Non-cyanide method for hemoglobin testing
Parameters :
23 Reportable Parameters CBC :
Whole Blood Mode: WBC, Lym#, Neu#, Mon#, Eos#, Bas#, Lym%, Neu%, Mon%, Eos%, Bas%, RBC, HGB, HCT, MCV, MCH, MCHC, ROW-CV, RDW-SD, PLT, MPV, PDW, PCT.
4 Research Parameters : ALY#, LIC#, ALY%, LIC%
3 Histograms : VVBC, RBC, PLT
3 Scattergrams for WBC Differential and 1 for Basophil measurement
Sample volume : CBC 9 μL
Counting modes : Venous whole blood, capillary whole blood, and pre-diluted blood
Reference value setting : Pediatrics, Male/Female adult, general and user-defined
Flagging system : Reliable alarm system with customized function
Linearity :
WBC : 0~300 x 109/L
RBC : 0~8.5 x 1012/L
HGB : 0~250g/L
HCT : 0~67%
PLT : 0~3000 x 109/L
Data storage capacity : up to 50,000 results including numeric and graphical data
Communication : LAN port support HL7 protocol
Interface : 4 USB porlt, 1 LAN connection support Bi-directional LIS
Printout : extrernal laser Printer/inkjek printer, various printoul formals and customized formats
Operating Environment : 10 C - 30C , 20%-85%, and air pressure 70kpa-106kpa
Power requirement : AC100v-240V (50/60Hz) <250VA
Display : 10.4” Intuitive color touch screen
Multi- Language : Chinese, English avallable
Dimension : 360 mm(L) x 470 mm (W) x 430 mm (H)
Weight : 28 Kg
