System function
Throughput up to 100 tests per hour
Contents of the testing ; clinical chemistry, immunoturbidimetric
Analytical modes; end-point, two-point, kinetic
Automatic, random access
STAT sample priority

Sample tray
Sample position :9 positions for sample
Sample volume : 3-45 ul, 0.5 ul adjustable
Any position for standard and quality control setting

Reagent tray
Sample position : 40 positions in refrigerated compartment
Reagent volume
RI ; 180-450 ul, 1 ul adjustable
R2; 3- 450 ul, 1 ul adjustable

Reaction tray
Reaction positions ;90cuvetters, 10 cuvettes/strip
Cuvette ; optical length 5 mm
Reaction volume ; 180-500 ul
Reaction temperature; 37ᴼC, fluctuation +0,3ᴼC

Probe
Pre-heating for reagent
Collision protection, liquid level detection and inventory cheking
Automatic inner and outer probe washing aftar every cycle, carry-over <0.1%

Measuring and optic system
Lamp; halogen lamp
Absorbance rang ; 0-3.500 Abs +1%
Wavelengths; 8 wavelengths from 320- 850nm including 340nm, 405nm, 450nm, 578nm, 630n, 670nm.
Resolution; 0.0001 Abs

Working condition
Power supply AC 110/220V 50/60 Hz
Temperature ; 0 – 35ᴼC
Humidity: 35 - 80%
Water consumtion ; max 2.5 L/hour
Dimension : 630cm (L)x 480mm(W)x510mm(H)
Gross weight : 70kg
