System function
Throughput up to 160 tests per hour
Contents of the testing ; clinical chemistry, immunoturbidimetric
Analytical modes; end-point, two-point, kinetic
Automatic, random access
STAT sample priority

Sample tray
Sample position : 40 positions for sample
Sample volume : 3-45 ul, 0.5 ul adjustable
Any position for standard and quality control setting
Reagent tray
Sample position : 40 positions in refrigerated compartment
Refrigerated temperature : 4-15ᴼC
Reagent volume
RI : 180-450 ul, 1 ul adjustable
R2 : 30-250 ul, 1 ul adjustable

Reaction tray
Reaction positions : 81 cuvetters, 8 cuvettes/strip
Cuvette : optical length 5 mm
Reaction volume : 180-500 ul
Reaction temperature : 37ᴼC, fluctuation +0,1ᴼC
Independent mixing probe
Cuvette washing (optional); automatic 10 steps washing system

Probe
Pre-heating for reagent
Collision protection, liquid level detection and inventory cheking
Automatic inner and outer probe washing aftar every cycle, carry-over <0.2%

Measuring and optic system
Lamp; halogen lamp
Absorbance rang : 0-3.500 Abs +1%
Wavelengths; 8 wavelengths from 340-700nm including 340nm, 405nm, 450nm, 578nm, 630n, 670nm.
Resolution : 0.0001 Abs

Working condition
Power supply AC 110/220V 50/60 Hz
Temperature : 0-40ᴼC
Humidity:<80%
Water consumtion: max 3 L/hour
Dimension :810cm (L)x680mm(W)x1150mm(H)
Gross weight : 145 kg
