Illuminating/viewing geometry : 8°:di (8°illumination angle/diffuse viewing: specular component included
(conforms to DIN 5033 Teil 7, JIS Z 8722 condition d, ISO 7724/1, CIE No. 15, ASTM E 116
Detector : Silicon photocells (6 pcs.)
Display range : L*: 1 to 100
Light source : Pulsed xenon lamps
Measurement time : Approx. 1 sec
Battery performance : Approx. 2,000 measurement at 10-sec. intervals when using alkaline-manganese batteries
Measurement area : Approx. ø8 mm, approx. ø5 mm (optional accessory) (*Optional ø5 mm mask does not conform to DIN 5033 Teil 7 and CIE N)
Repeatability : Standard deviation within ΔE*ab 0.1 (when a white calibration plate is measured 30 times at 10-second intervals)
Display languages : English, Simplified Chinese, Japanese
Interface : USB2.0
Observer : 10° Standard Observer
Illuminant : D65
Display data : Color difference, average (up to 10 times), Pass/fail judgment
Color different formula : Δ (L*a*b*), Δ (L*C*H*), Δ E*ab (CIE 1976)
Data memory : Target data, Samples data(up to 1,000 in total)
Pass/fail item : Δ E*ab, Δ (L*a*b*), Δ (L*C*H*)
Operation temperature/ humidity range : 0 to 40°C, relative humidity 85% or less (at 35°C) with no condensation
Storage temperature/ humidity range : -20 to 40°C, relative humidity 85% or less (at 35°C) with no condensation
Power : 4 AA-size alkaline dry batteries or nickel-metal-hydride rechargeable batteries, USB bus power or special AC Adapter
Size (W x H x D) : 66 x 158 x 85 mm
Weight : 420 g (without batteries)
