Gauge pressure range : 0 to 500 psi (35 bar)
Accuracy : 0.1% FS
Media : Gas and liquid
Display :
Wide viewing angle FSTN segment code LCD, three partition design
White backlight
4 or 5 digit display (switchable). Numeral display height: 14.5mm (0.57"
Pressure units :
Pa, kPa, MPa, psi, bar, mbar, kgf/cm2, %,inH2O@4°C,mmH2O@4°C, inHg@0°C, mmHg@0°C
6 engineering water columns:inH2O(20°C) , inH2O(60°F) , mmH2O(20°C) , mmH2O(15°C) , ftH2O(60°F) , ftH2O(4°C)
1 custom unit: identified by the USER icon. The conversion coefficient can be set via Additel Link mobile app
Pressure port :
≤15,000 psi: 1/4NPT male, 1/2NPT male, 1/4BSP male, 1/2BSP male, M20×1.5 male
>15,000 psi: 1/4HP female or 1/4HP male
*1/4HP female: Autoclave F-250-C, 9/16" - 18 UNF-2B
*1/4HP male: Autoclave M-250-C, 9/16" - 18 UNF-2A
Power :
3 AA alkaline batteries (included), it can also be powered externally through the RS232 cable
Power auto-off: 120, 90, 60, 45, 30, 15, minute auto-off options
The factory default of power auto-off feature is inactive
Compliance :
Protection Level: IP67(working media is liquid)
Vibration: 5 g (20-2000 Hz)
Shock Resistance: 10 g
Communication : Bluetooth, RS232 *(Do not use the RS-232 connector in a hazardous areas)
Calibration : ISO 17025 Accredited Calibration Certificate with data
Overpressure alarm : Display will flash over 120%FS
Dimension: Ø4.13" x 1.83" x 5.84"(105mm x 46.5 mm x 148.5 mm)
Weight: 1.27 lbs (0.58 kg)
