Gauge pressure range : 150 psi (10 bar)
Accuracy : 0.05% FS
Media : Gas and liquid
Display :
Wide viewing angle FSTN segment code LCD, three partition design
White backlight
4 or 5 digit display (switchable). Numeral display height: 14.5mm (0.57"
Pressure units :
Pa, kPa, MPa, psi, bar, mbar, kgf/cm2, %,inH2O@4°C,mmH2O@4°C, inHg@0°C, mmHg@0°C
6 engineering water columns:inH2O(20°C) , inH2O(60°F) , mmH2O(20°C) , mmH2O(15°C) , ftH2O(60°F) , ftH2O(4°C)
1 custom unit: identified by the USER icon. The conversion coefficient can be set via Additel Link mobile app
Pressure port :
≤15,000 psi: 1/4NPT male, 1/2NPT male, 1/4BSP male, 1/2BSP male, M20×1.5 male
>15,000 psi: 1/4HP female or 1/4HP male
*1/4HP female: Autoclave F-250-C, 9/16" - 18 UNF-2B
*1/4HP male: Autoclave M-250-C, 9/16" - 18 UNF-2A
Power :
Battery life:
1. Super stable mode[1]: 4000 hours (3 reading/s, default), 1000 hours (10 reading/s)
2. Low power mode[2]: 5000 hours (2 reading/s), 9000 hours (1 reading/s), 18000 hours (1 reading/10s)
Power auto-off: 120, 90, 60, 45, 30, 15 minute auto-off options or never
Compliance :
Protection Level: IP67(working media is liquid)
Vibration: 5 g (20-2000 Hz)
Shock Resistance: 10 g
Communication : Bluetooth (BLE4.2), USB-C, RS232 *(Do not use the USB-C or RS-232 connector in a hazardous area)
Calibration : ISO 17025 Accredited Calibration Certificate with data
Overpressure alarm : Display will flash over 120%FS
Dimension : Ø4.65" x 1.65" depth x 7" height (Ø118 mm x 42 mm depth x 178 mm height)
Weight : 1.5 lbs (0.68 kg)
