Display : 2.7″ high-brightness, color touchscreen, readable in all lighting conditions.
Rear-facing display for easy results viewing.
Power : On-board rechargeable Li-ion battery, rechargeable inside device or with external charger, AC power.
Processing Electronics : ARM Quad Cortex -A53 1.2 GHz Memory: 2 GB LPDDR3, 16 GB eMMC
Data Storage : Results storage: 32 GB SD
Connectivity : Built on Google’s Android platform for real-time data exporting, including
built-in WiFi (IEEE 802.11b/g/n), Bluetooth (BR/EDR+BLE), GPS and USB-C to connect to virtually any information management system.
Sample Viewing : Integrated camera and laser target indicator for viewing sample before
and during analysis for proper sample alignment. Includes second “macro camera” for scanning QR or barcodes and for photo-documentation and report generation.
Laser Raster : On-board Y stage for rastering laser to discrete locations for targeted analysis or averaging.
Atmosphere : SciAps proprietary Opti-Purge provides an inert argon environment, improving spectral signal-to-noise ratio and improving performance in the
UV range.
Calibration Check : 316 stainless steel standard for automated calibration and wavelength
scale validation.
Drift Correction : On-board automated drift correction software with factory-provided or user-provided reference materials.
Grade Library : 500+ grades, multi-library support, libraries may be added or edited.
Regulatory : CE, RoHS, USFDA registered. Class 3b laser. Sample sensor on board, allows for operation under Class 1 conditions, subject to local LSO approval.
Spectral Range : 190 – 420 nm
Calibrations :
Aluminum: Be, Mg, Al, Si, Ti, V, Cr, Mn, Fe, Ni, Cu, Zn, Zr, Pb, Bi, Ag, Sn
Titanium Base: Al, Ti, V, Cr, Fe, Cu, Zr, Nb, Mo, Sn
LAS Base: C, Al, Si, Ti, V, Cr, Mn, Fe, Cu, Ni, Nb, Mo, Pb
Stainless Steels: C, Al, Si, Ti, V, Cr, Mn, Ni, Fe, Ni, Cu, Nb, Mo, W
Nickel Base: Al, Si, Ti, Cr, Mn, Fe, Co, Ni, Cu, Nb, Mo, W
Copper Base: Be, Al, Si, Cr, Mn, Fe, Ni, Cu, Zn, Ag, Sn, Pb, Bi
Cobalt Base: Al, Si, Ti, Cr, Mn, Fe, Co, Ni, Cu, Nb, Mo, W
Specialty Bases: Mg, V, Cr, Mn, Co, Zn, Zr, Nb, Mo, Ag, Sn, Hf, Ta, W, Re, Pb, Sn.
Security : Password protected; Multi-user support with configurable access settings
Dimensions : 10.75 x 2.875 x 8.625 inches
Weight : 4.35 lbs. (1.97 kg) with battery
