Display : 2.7″ high brightness, color touchscreen, readable in all lighting conditions. Rear
facing display for easy results viewing.
Power : On-board rechargeable Li-ion battery, rechargeable inside device or with
external charger, AC power.
Processing Electronics : ARM Quad Cortex -A53 1.2 GHz Memory: 2 GB LPDDR3, eMMC 16 GB
Data Storage : Results Storage: 8 GB SD
Connectivity : Built on Google’s Android platform for real-time data exporting, including
built-in Wifi, Bluetooth, GPS and USB to connect to virtually any information management system.
Sample Viewing : On-board, auto-focus camera/video for viewing sample before and during analysis, laser spot finder to show where laser strikes sample. Includes 2nd “macro camera” for viewing sample, reading 3d bar-codes for photodocumentation and report generation.
Laser Raster : On-board Y stage for rastering laser to discrete locations for targeted analysis or
averaging. Typically, raster in 3 locations.
Excitation Source : 5-6 mJ/pulse, 50 Hz repetition rate, 1064 nm laser source
Operation: Air Burn. Optional “Dual Burn” Technology available : The Z-9 operates in air-burn environment, no argon purge required. Users may add argon-purge at time of purchase or later, to operate with either air or argon purge capability.
Calibration Check : 316 stainless steel standard for automated calibration and wavelength
scale validation.
Drift Correction : On-board automated drift correction software with factory provided or user
provided reference materials.
Grade Library (alloy) : 500+ grades, multi-library support, libraries may be added/edited with PC
software package (ProfileBuilder).
Regulatory : CE, RoHS, USFDA registered. Class 3b laser. Sample sensor on board, allows for
operation under Class 1 conditions, subject to local LSO approval.
Spectrometer/Range : 200 nm – 420 nm
Analytical Range : Typically, 15-20 elements calibrated, specific elements depending on alloy base.
Security : Password protected usage (user level) and internal settings (admin)
Dimensions : 10.75" x 2.375" x 8.625"
Weight : 3.5 lbs. with battery
