Display : 3.5″ high-brightness, color touchscreen, readable in all lighting conditions. Rear-facing display for easy results viewing.
Power : On-board rechargeable Li-ion battery, rechargeable inside device or with
external charger, AC power.
Processing Electronics : ARM Quad Cortex -A53 1.2 GHz Memory: 2 GB LPDDR3, 16 GB eMMC
Data Storage : Results storage: 32 GB SD
Connectivity : Built on Google’s Android platform for real-time data exporting, including built-in WiFi (IEEE 802.11b/g/n), Bluetooth (BR/EDR+BLE), GPS and USB-C to connect to virtually any information management system.
Sample Viewing : Integrated camera and laser target indicator for viewing sample before and during analysis for proper sample alignment. Includes second “macro camera” for scanning QR or barcodes and for photo-documentation and report generation.
Laser Raster : On-board 3 dimensional stage for rastering laser to discrete locations for
targeted analysis or averaging.
Atmosphere : SciAps proprietary Opti-Purge provides an inert argon environment, improving spectral signal-to-noise ratio and improving performance in the UV range.
Calibration Check : 316 stainless steel standard for automated calibration and wavelength scale validation.
Drift Correction : On-board automated drift correction software with factory-provided or user-provided reference materials.
Regulatory : CE, RoHS, USFDA registered. Class 3b laser. Sample sensor on board, allows for operation under Class 1 conditions, subject to local LSO approval.
Spectral Range : 190 - 950 nm
Calibrations : Factory provided Geochem calibration and Profile Builder software allow users to build their own matrix matched calibrations.
Security : Password protected; multi-user support with configurable access settings.
Dimensions : 10.6 x 3.25 x 10.6 inches
Weight : 4.93 lbs. (2.24 kg) with battery
