Display : 2.7″ high brightness, color touchscreen, readable in all lighting conditions.
Rear facing display for easy results viewing.
Power : On-board rechargeable Li-ion battery, rechargeable inside device or with external charger, AC power.
Processing electronics : ARM Quad Cortex -A53 1.2 GHz Memory: 2 GB LPDDR3, eMMC 16 GB
Data storage : Results Storage: 32 GB SD card
Connectivity : Built on Google’s Android platform for real-time data exporting, including built-in WiFi (IEEE 802.11b/g/n), Bluetooth (BR/EDR+BLE), GPS and USB-Cto connect to virtually any information management system.
Sample viewing : Integrated camera and laser target indicator for viewing sample before and during analysis for proper sample alignment. Includes second “macro camera” for scanning QR or bar codes and for photo-documentation and report generation.
Laser raster : On-board Y stage for rastering laser to discrete locations for targeted analysis or averaging.
Atmosphere : SciAps proprietary Opti-Purge provides an inert argon environment improving spectral signal to noise ratio and improving performance in the UV range.
Calibration check : 316 stainless steel standard for automated calibration and wavelength scale validation.
Drift correction : On-board automated drift correction software with factory-provided or user-provided reference materials.
Regulatory : CE, RoHS, USFDA registered. Class 3b laser. Sample sensor on board, allows for operation under Class 1 conditions, subject to local LSO approval.
Spectral range : 350–675 nm
Calibrations : Li in pegmatites, Li in clay, Li in mica-schists. Additional matrix matched
calibrations can be built by operator using Profile Builder software for PC and tablet.
Security : Password protected; Multi-user support with configurable access settings
Dimensions : 10.75" x 2.375" x 8.625"
Weight : 3.87 lbs. with battery
