Power : On-board rechargeable Li-ion battery, rechargeable inside device or with external
charger, and AC power.
Display : 5″ color touch screen, smartphone-type display – PowerVR SGX540 3D graphic
Sample Viewing : Internal camera for viewing sample before and during analysis for proper sample alignment. Second macro-camera for scanning QR or barcodes and for photo-documentation and report generation.
Comms/Data Transfer : Wi-Fi, Bluetooth, USB. Connectivity to most devices, including SciAps Profile
Builder PC software.
Excitation Source : 6-40kV, 200uA Rh anode for alloy testing, 6-50kV, 200uA Au anode for most
other apps.
Detector : 20mm² silicon drift detector (active area), 135eV resolution FWHM at 5.95Mn K alpha line.
X-Ray Filtering : 6-position filter wheel for beam optimization.
Processor : ARM Cortex -A9 dual-core / 1.2GHz Memory: 1GB DDR2 RAM, 1GB NAND
Pulse Processor : 14-bit ADC with digitization rate of 80 MSPS 8K channel MCA USB 2.0 for high speed data transfer to host processor; digital filtering implemented in FPGA for high throughput pulse processing 50nS – 24uS peaking time
Calibration : Fundamental Parameters, Compton Normalization, and/or Compton Normalization for Alloy. Geochem, Environmental and Soil calibrations.
Calibration Check : Internal shutter is also 316 stainless for totally automated calibration and energy scale validation.
Environmental Temp. Range : 10°F to 130°F at 25% duty cycle.
Security : Password protected usage (user level) and internal settings (admin).
Regulatory : CE, RoHS, USFDA registered, Canada RED Act.
Dimensions : 9.38in (238mm) x 11.15in (283mm) x 3.34in (84mm)
Weight : 3.1 lbs with battery
