Excitation Source : 4 W, 40kv Rh on alloys 50kv Au on other apps.
Detector : 7 mm2 PIN diode detector (active area), 200 eV resolution FWHM at
5.95 Mn K-alpha line.
Available Apps: Alloy analysis, Precious Metals, Soil, Mining, Car Cats..
X-ray Filtering : Single primary beam filter for alloy, mining, precious metals. Multiple filters
for soil, RoHS, car catalysts and some other apps.
Environmental Temperature Range : 10F to 130F at 25% (-12.2C to 54.44C) duty cycle
Analytical Range : 24 elements standard, specific elements vary by app. Ti, V, Cr, Mn, Fe, Co,
Ni, Cu, Zn, W, Ta, Hf, Re, Se, Au, Pb, Bi, Zr, Mo, Pd, Ag, Cd, Sn, and Sb. Additional elements may be added upon user request. Precious Metals app is 23 elements standard.
Processing Electronics and Host Processing : 1.2GHz quad ARM Cortex A53 64/32-bit, RAM: 2GB LP-DDR3, Storage: 16 GB eMMC (storage)
Pulse Processor : 12 bit with digitization rate of 80 MSPS 8K channel MCA USB 2.0 for high speed data transfer to host processor. Digital filtering implemented in FPGA for high throughput pulse processing 20 nS - 24 uS peaking time.
Power : On-board rechargeable Li-ion battery, rechargeable inside device or with
external charger, AC power. Hot-swap battery capable.
Display : 3.5-inch(88.9mm) color capacitive touchscreen — 400 MHz Qualcomm
Adreno 306 2D/3D graphics accelerator
Sample Viewing : Internal camera for viewing sample before and during analysis for proper sample alignment. Second macro-camera for scanning QR or barcodes and for photo-documentation and report generation.
Comms/Data Transfer : Wi-Fi, Bluetooth, USB connectivity to most devices, including SciAps Profile
Builder PC software. SciAps Cloud data management options available.
Calibration : Fundamental parameters.
Calibration Check : External 316 stainless check standard for calibration verification and energy scale validation.
Security : Password protected usage (user level) and internal settings (admin).
Dual Cameras : Internal high-resolution camera for sample viewing, welds, etc. Macro camera for photo documentation, reading and storing 2D/3D barcodes and QR codes.
Regulatory : CE, RoHS, USFDA registered, Canada RED Act.
Dimensions : 9.38in (238mm) x 11.15in (283mm) x 3.34in (84mm)
Weight : 3.1 lbs. ( 1.40kg) with battery
