Excitation Source : 5 W X-ray tube. Typical: 40 kV, 200 uA Rh or Au anode. Anode choice
depends on what other apps users may want to add.
Detector : 20 mm² silicon drift detector (active area), 140 eV resolution FWHM at 5.95 Mn K-alpha line.
Available Apps : Lead Paint App based on published PCS standard. Optional apps include Lead in soil, Alloy, Geochem (Mining), Empirical, Environmental Metals. Coming soon: Lead in dust wipes and air filters (NIOSH 7702).
X-ray Filtering : Standard 1 position filter. Upgradeable to 5 positions depending on additional apps added.
Environmental Temperature Range : 10° F to 130° F at 25% duty cycle.
Analytical Range : Pb standard. Analyzer may be calibrated to report up to 32 elements with appropriate upgrades.
Processing Electronics and Host Processing : 1.2 GHz quad ARM Cortex A53 64/32-bit; RAM: 2 GB LP-DDR3; Storage: 16 GB eMMC (storage).
Pulse Processor : 12 bit with digitization rate of 80 MSPS 8K channel MCA USB 2.0 for high speed data transfer to host processor. Digital filtering implemented in FPGA for high throughput pulse processing, 20 nS - 24 uS peaking time.
Power : On-board rechargeable Li-ion battery, rechargeable inside device or with external charger, AC power, hot-swap capability (60 s max swap time).
Display : 2.7-inch color capacitive touchscreen — 400 MHz Qualcomm Adreno 306
2D/3D graphics accelerator.
Comms/Data Transfer : Wi-Fi, Bluetooth, USB connectivity to most devices, including SciAps Profile
Builder PC software.
Calibration : Linear or quadratic lead calibration with absorption and depth corrections.
Calibration Check : External 316 stainless check standard for energy-scale calibration verification. NIST 1.04 mg/cm2 lead paint standard on wooden substrate block for PCS calibration check standard, with other lead levels available for alternative action levels.
Security : Password protected usage (user level) and internal settings (admin).
Regulatory : CE, RoHS, USFDA registered, Canada RED Act.
Dimensions : 8.5" x 9.5" x 2.4"
Weight : 2.98 lbs. with battery.
