Excitation Source : 5 W X-ray Tube. Max 55 kV, 200 uA. Au anode
Detector : 20 mm2 silicon drift detector (active area), 140 eV resolution FWHM at 5.95 Mn K-alpha line
Available Apps : Soils, RoHS/WEEE, REE, Mining. New apps are added regularly, please check with SciAps for updates.
X-ray Filtering : Six position filter wheel
Environmental Temperature Range : 10F to 130F at 50% duty cycle
Analytical Range : 32 elements standard, specific elements vary by app. Additional elements
may be added upon user request.
Processing Electronics and Host Processing : 1.2GHz Quad ARM Cortex A53 64/32-bit, RAM 2GB LP-DDR3,
Storage: 16 GB eMMC (storage)
Pulse Processor : 12 bit with digitization rate of 80 MSPS 8K channel MCA USB 2.0 for highspeed data transfer to host processor. Digital filtering implemented in FPGA for high throughput pulse processing 20 nS - 24 uS peaking time.
Power : On-board rechargeable Li-ion battery, rechargeable inside device or with external charger, AC power, hot-swap capability (60 s max swap time).
Display : 2.7-inch color capacitive touchscreen — 400 MHz Qualcomm Adreno 306 2D/3D graphics accelerator
Comms/Data Transfer : Wifi, Bluetooth, USB connectivity to most devices, including SciAps ProfileBuilder PC software
Calibration : Fundamental parameters. For Geochem and Environmental Soil apps, users may also choose “Compton Normalization” method and/or use empirically derived calibrations.
Calibration Check : External 316 stainless check standard for calibration verification and energy
scale validation
Security : Password protected usage (user level) and internal settings (admin)
Regulatory : CE, RoHS, USFDA registered, Canada RED Act
Dimensions : 7.25" x 10.5" x 4.5"
Weight : 2.98 lbs. with battery
