Spesifikasi:
Model: DTR2500-27 - DTR2500-27
Spectral Range (cm-1): 250-2700 - 200-4000
Resolution (cm-1): 4〜6 - 7〜10
SNR: >1300:1 (918 cm-1of Acetonitrile，4sIntergation, 130mW)
Interface: USB 2.0
Integration time: 4ms – 120s
Voltage: DC 5V±5%
Work temperature: -10〜45℃
Work humidity: < 95%
Dimension(L*W*H): Without probe ： 119.2x89x35 mm; With probe ： 139x89x35 mm
Weight: 390 g
Model:Ultra-sensitive linear array detector
Spectral range: 200-1100 nm
Effective pixels: 2048 pixels
Dynamic range: 50000: 1
Center wavelength: 785士0.5nm
Half width; 0.08 nm
Maximum output power: >300 mW, the actual output power software can be se
Minimum power output adjustment: 1mW
Power stability: σ/μ <士0.2%
