Spesifikasi:
Interface: USB 2.0/LAN
OS: Android 4.4.2
Battery endurance: >3 h
Integration time: 4ms – 120s
Spectral stability: σ/μ < 0.5% (COT 8 hours)
Temperature stability: Spectral shift ≤ 1 cm-1 (10-40 ℃)
Variation of Spectral intensity in 5 ~ 40 ℃: <±5%
Supply voltage: DC 19V(+/-5%)
Operating temperature: 5~40 ℃
Operating humidity: < 95%
Spectral region: 250-2400 cm-1
Spectral resolution:2 cm-1@900nm
Signal-to-Noise: >3000:1 (918 cm-1 of Acetonitrile，10s accumulation, 200mW)
Incidence slit: 50 μm
Type: Ultra-high sensitive FFT-CCD with TEC cooling
Detectable range: 200-1100 nm
Effective pixel: 2048*64
Dynamic range: 50000：1
Pixel dimension: 14μm×14μm
Full well capacity: 300 Ke-
Sensitivity: QE>40%, 6.5 μV/e-
Optical system: f/4 Crossed Symmetrical Czerny-Turner
Focal length; 98 mm for incidence and output
Size (L*W*H): 30×22.5×13.2 cm3
Weight: 7.5 Kg
