Spesifikasi:
Interface: USB2.0
Integration time: 1ms-120s
Power voltage: DC 5V(+/-5%)
Operating Temp: -10~40 ℃
Operating humidity: < 95%
Dimension(L*W*H): 33x26x14cm3
Weight: 5Kg
Spectral stability: σ/μ < 0.5%(COT8hours)
Temp stability: Spectral shift ≤ 1cm-1(10-40℃)
Variation of intensity: <±5%
Spectral range (cm-1): 200-3600
resolution (cm-1): 7-8
SNR: >1500:1
Entrance slit: f/4 C-T crossed optical path
Optical system: 98mm for incidence and output
Item: Ultra-high sensitivity, quick cooled-CCD
Temp cooled down to: -10
Detector range: 200-1100nm
Effective pixels: 2048*64
Dynamic range: >10000： 1
Pixel size: 14 X200μ m
Central wavelength:532nm (+/-0.5nm)
FWHM: ≤0.1nm
Power output: ≥100mW
Power stability; σ/μ <±0.5%
Operating distance: 3mm
Rayleigh scattering resistance; OD>8
Numerical Aperture: 0.3
Aperture; 7mm
