Spesifikasi:
Interface: USB 2.0/LAN
Operate system: Windows
Integration time: 1ms – 64s
Power voltage: DC 5V(+/-5%)
Operate temp.: -5~40 °C
Operate humidity: < 95%
Size (L*W*H): 33×25.6×16.5cm3
Weight: 5.2Kg
Spectral stability: σ/μ < 0.5%(COT8hours)
Temp. stability: < 1cm-1(5-40 °C)
Spectral intensity shift (in5~40 °C): <±5%
Spectral range: 200-3700cm-1
Resolution: 12cm-1
SNR: >1500:1
Incident slit; 50μm
Optical path: f/4 C-T
Focus distance: 98 mm for incidence and output
Model: Ultra-high sensitivity TE-cooled CCD
Effective pixels: 2048
Dynamic range: 50000:1
Pixel size: 14μmx200μm
Full well capacity: 300 Ke-
Sensitivity: 25 μV/e-
Central wavelength: 633nm (±0.5nm)
FWHM: <0.1nm
Power output: <50mW
Power stability: σ/μ <±0.5%
Working distance: 6mm
Rayleigh scattering resistance: OD>8
Numerical aperture: 0.3
Light through aperture: 7mm
