Spesifikasi:
Czerny-Turner monochromator
Diffraction Grating： Groove 1800lines/mm， blaze wavelength 250nm
Focal Length：277mm
Spectral Bandwidth： 0.1nm, 0.2nm, 0.4nm, 0.8nm, 1.6nm
automatically change（Model A）
0.1nm, 0.2nm, 0.4nm, and 1.2nm automatically change（Model B）
Automatic peak-picking, automatic spectral bandwidth setting, automatic energy, and wavelength optimization.
Wavelength Range: 190nm ~ 900nm
Light Source:
8-lamp turret automatically rotates and aligns
2 positions for High performance lamp.
8-lamp power on and multiple lamp preheat at the same time.
Lamp current range: 0~15mA
Power Supply:
Main Unit for model A：Single phase AC, 110V/220V，max power consumption: 0.2kVA
Main Unit for model B：Single phase AC, 110V/220V，max power consumption: 0.15kVA
GF Power Supply for model A：Single phase AC, 220V，max power consumption: 5.5kVA
Dimensions & Weight:
Main Unit for Type A：1020mm（L）×530mm（W）×500mm（H），85kg
Main Unit for Type B：1020mm（L）×530mm（W）×500mm（H），80kg
GF Power Supply for Type A：350mm（L）×490mm（W）×430mm（H），40kg
