Spesifikasi:
Wavelength range: 190 – 900nm
Spectral bandwidth: 0.1, 0.2, 0.4, 1.0 and 2.0nm
Accuracy of the wavelength: ±0.15nm
Receptivity of the wavelength: ≤0.04nm
Base line stability: ≤0.002A/30min (Cu)
Characteristic viscosity: 0.02μg/ml/1% (Cu)
Checking limit: 0.004μg/ml (Cu)
Preciseness: 0.50%
Grating: 1800 lines/mm
Inflamer: All-metal titanium burner
Atomizer: Effective glass atomizer
Lamp stand: 8
Acetylene air burner: 100mm
Ignition dynamic baseline drift: ≤0.006A/30min
(Cu) Characteristic viscosity: ≤0.025μg/ml/1%
The highest temperature: 3000℃
The largest temperature rising speed: ≥2000℃/S
Characteristic quantity: Cd≤0.5×10-12g Cu≤0.5×10-11g
Accuracy: Cu≤3% Cd≤3%
Size and weight: 550mm×450mm×300mm 65Kg
Safety system:
Over-current protection Low air pressure alarm/protection
Low cooling water flow alarm/protection
Power source and power: 220V±22V AC 7000W
