Spesifikasi:
Size: 430(L)×380(W)×355(H)mm
Weight: 34kg
X-ray source:
X-ray tube: W target (Rh target and Ag target are optional)
Voltage of X-ray tube: 0-50KV, adjustable
Current of X-ray tube: 0-1mA, adjustable
Refrigeration of X-ray tube: closed style air cooling
Collimating system: Φ1.5mm for standard allocation (optional upon requests)
X-ray detection system: proportional counter
Sample observation system:
Sample illumination: LEC lamp, inferior vertical irradiation
Sample observation: CCD high definition camera
Angle between bare tube rays and horizontal direction: 45 degree
Size of sample chamber: 306(W) x 260(H) x 78(D) mm
Safety protection: when the lid of the instrument is not fully closed, the high pressurewon’twork then.
Data acquisition: 2048 ways of subdividing data acquisition
Power supply: voltage input: AC220V/110V±10%,≤3A,50/60HZ
Range of measurable elements: Au, Ag, Cu, Zn, Ni etc.
Sample form: Solid
Long-term operating stability: 0.1% (Au≥95%)
