Spesifikasi:
Elemental Analysis Range: Fluorine (F) to Uranium (U)
Analytical Detection Limit: As low as 0.2 ppm (for light matrices)
Analytical Range: ppm to 99.99%
Analytical Accuracy: <0.05% (RSD value for multiple repeated measurements of main elements in samples witha content >96%)
Detector Energy Resolution: SDD detector, ≤129eV
Excitation Source: Tube voltage 5~50kV, tube current 0~1000uA
High Voltage Generator: Imported Spellman High Voltage
Testing Atmosphere: Atmospheric, Vacuum, Helium
Sample Introduction System: 9 sample chambers (with cup rotation), 12 sample chambers + single chamber, 20 sample chambers + single chamber (optional), controlled by PLC
Any number of automatically matchable or selectable analysis and identification models.
Mutually independent matrix effect correction model.
Multivariate nonlinear regression program.
Temperature Range: 15°C to 30°C
Power Supply: AC 220V ± 5V, recommended to configure with AC purified stabilized power supply
Instrument Size: 646 (W) × 578 (D) × 388 (H) mm
Sample Chamber Size: Φ340 × 64 (H) mm
Instrument Weight: 85KG
