Spesifikasi:
Analytical Method: Energy Dispersive X-ray fluorescence analytical Method
Elements Measuring Range:
Atomic number from 12 to 92
[elements from magnesium(Mg) to uranium (U)J can be measured
Simultaneous detector elements: Simultaneous analysis 40 elements
Microcomputer system: Customized system; CPU: 1G ; system memory: 1G ; extended stored maximum support 32G ; standard 4G for mass storage data
The content range: ppm ~ 99.99%
The detection time: 1 〜60 seconds (a second report results)
A built-in system: GPS, WIFI, Bluetooth
Power Supply: Rechargeable lithium battery, standard is 9000mAh, sustainable work up to 12 hours; optional is 27000mAh superbattery with wide voltage 110V ~ 220V universal adapter for recharging power supply
Detection Objective: Solid, liquid, powder
Detector: SDD detector or Fast-SDD detector (optional)
Detector resolution: Minimum can reach 128eV
The excitation source: 50KV/200uA- silver target end window integrated miniature X ray tube and high voltage power supply
Collimator and filter: Collimator diameters are 4.0mm and 2.0mm, 6 kinds of filters with automatic switching functions
Video system: 500W pixel high resolution camera
Display screen: Brand new 5 inch transflective LCD touch screen, the resolution is 1080 x 720
Detection limit: The minimum detection limits at 1 ~ 500 ppm
Operating ambient humidity: 《90%
Operating environmental temperature: -20°C~+50°C
Instrument dimension: 244mm ( Length) x 90mm (Width) x330mm ( Height)
Instrument weight: 1.7Kg
