Spesifikasi:
Analytical Method: Energy dispersive X ray fluorescence analytical Method
Elements Measuring Range: tomic number from 12 to 92
[elements from magnesium (Mg) to uranium (U)] can be measured
Simultaneous detector elements: Simultaneous analyze 40 elements
Microcomputer system Customized system; CPU: 1G ;
System memory: 1G ; extended stored maximum support 32G ;
Standard 4G for mass storage data
The content range: ppm ~ 99.99%
The detection time: 1〜60 seconds (one second report results)
A built-in system: GPS, WIFI, Bluetooth
Power Supply: Rechargeable lithium battery, standard is 9000mAh, sustainable work up to 12 hours; optional is 27000mAh superbattery with wide voltage 110V ~ 220V universal adapter for recharging power supply
Detection Objective: Solid, liquid, powder
Detector: SDD detector or Fast-SDD detector (optional)
Detector resolution: Minimum can reach 128eV
The excitation source: 50KV/200uA- silver target end window integrated miniature X-ray tube and high voltage power supply
Collimator and filter: Collimator diameters are 4.0mm and 2.0mm, 6 kinds of filters with automatic switching functions
Video system: 500W pixel high resolution camera
Display screen: Brand new 5 inch semi-reflecting and semi-transmitting LCD touch screen, its resolution is 1080*720.
Operating environmental temperature: -20°C~+50°C
Instrument dimension: 244mm ( Length) x 90mm (Width) x330mm ( Height)
Instrument weight: 1.7Kg
