Spesifikasi:
Interferometer: Cube-corner Michelson interferometer
Beam splitter: Multilayer Ge coated KBr
Detector: DLATGSMCT detector (optional)
IR Source: High intensity, long lifetime, air-cooled IR source
Wavenumber Range: 7800cm-1~350cm-1
Resolution: 0.85 cm-1
Signal to noise ratio: Better than 40,000:1 (RMS value, at 2100cm-1 ~ 2200cm-1, resolution: 4cm-1, 1 minute data collection)
Wavenumber Accuracy: ±0.01 cm-1
Scanning Speed: Microprocessor control, different scanning speed selectable.
Software: MainFTOS Suite software workstation, compatible to all version Windows OS
Optional Software: FDA 21 CFR Part11 compliance software (optional)
Interface: Ethernet & WIFI wireless
Data Output: Standard data format, report generation and output
Status Diagnosis: Power on self-check, real-time temperature and humidity monitoring and reminders
Certification: CEIQ/OQ/PQ (optional)
Environment Conditions: Temperature: 10℃～30℃, humidity: less than 60%
Power Supply: AC220V/±22V, 50Hz/±1HzAC110V,60Hz (optional,free)
Dimensions & Weight: 490×420×240 mm, 23.2kg
Standard Accessories: Transmission sample holder
Optional Accessories: Such as gas cell, liquid cell, Defused/Specular Reflection, single/multiple reflection ATR, IR Microscope etc.
