Spesifikasi:
Input Power: AC 220V, 20A
Output power: 700-1600W
Accuracy: 2W
Working Frequency: 27.12MHz
Frequency stability: <0.05%
Output power stability: <0.1%
Match method: auto-matching
Electromagnetic leakage radiation intensity: electric field intensity E <0.5V / m at 30cm away from the chamber
Output coil: Inner-diameter 25mm, 3 turns
Quartz tri-concentric torch: Outer-diameter 20mm. Various center channel size models optional
High-efficient nebulizer: Concentric nebulizer outer-diameter 6mm. Vvarious models ( high-salt,anti-HF, etc.)optional
Spray chamber: Scott spray chamber, the cyclonic spray chamber with outer diameter 57.2mm optional
Peristaltic pump: 12-roller, 4-channel, the rotation speed can be adjusted according to the demanded flow
Total consumption(Ar):
<14L/min
Plasma gas flow meter (100-1000)L/h (1.6-16L/min)
Argon flow meter/carrier: Auxiliary gas flow meter(6-60)L/h (0.1-1 L/min)
Gas pressure gauge: Carrier gas flow meter(6-60)L/h (0.1-1 L/min)
Specifications:
Carrier gas regulator valve (0.2MPa)
Cooling water: Water temp. 20-25″C Flow> 5L/min Pressure> 0.1MPa
View mode: Radial view
Liquid content: 0.01 ppm- several thousands ppm
Solid content: 0.001%—70%
Repeatability: (short-term stability) relative standard deviation RSD <0.5%
Stability: Relative standard deviation RSD <1 % within 2 Hours
Analysis speed: Single line CID readout time is 2ms, analysis for all elements can be achieved within one minute
Detection limit (pg/L): 1 ppb-10ppb for most elements
Instrument size: Desktop 1300mm*840mm*740mm
