Spesifikasi:
Rated power: 3kW
Tube voltage: 10-60kV
Tube current: 5-80mA
X-ray tuble: glass tube, ceramic tube, ripple ceramic tube: Cu, Fe, Co, Cr, Mo etc, Power 2kW
Focus size: 1 x 10mm or 0.4 x 14mm or 2 x 12mm
StabilityL ≤0.01%
Goniometer structure: Horizontal ( θ-2 θ)
Radius of diffraction: 185m
Scanning range: 0-164
Scanning speed: 0.0012° – 70° min
Max. revolving speed: 100° /min
Scanning fashion: θ-2θ linkage, θ、2θ single action; continuous or stepping scanning
Angle repeatable accuracy: 1/1000°
Minimal stepping angle: 1/1000°
Counting fashion: differential coefficient or integral, PHA automatically, Dead time regulate
Stability of system measure: ≤0.01%
Scattered rays dose: ≤1 μ Sv/h ( without X-ray protective device )
Instrument integrative stability: ≤0.5%
Figure size: 1100 x 850 x 1750mm
