Spesifikasi:
Measurable range of coating: 3Li~92U
Element detection range: 13AI~92U
Number of elements to bedetected simultaneously: 24 elements, and more
than five coatings can be analyzed at the same time
Detection limit: The thinnest metal coating can reach 0.005μm
Thickness range : Analysis coating thickness is generally within
50μm(variable for different materials)
Standard deviation of thickness: RSD<3%
Content test range: 0.1%–99.99%
Content detection accuracy: 0.5%
Content stability: The repeatability of multiple measurements can reach 0.5%
Detection time : 5-40 seconds
Lifting range of Z-axis of platform: 0~140mm
Detector and resolution: 25mm²Be window Fast- SDD semiconductor detector with resolution140±5eV
Multichannl analyser: DMCA digital multi-channel analysis
technology with 4096 channels
Collimator: Optional 0.1*0.3mm,φ0.2mm,φ0.3mm,φ0.5mm and other apertures
Minimum test area: 0.02mm²
Sample observation: Equipped with CCD colorful camera,
the image can be magnified up to 25 times, which can realize clear positioning of tiny samples
Sample moving platform: Full-automatic high-precision multi-point TEST XY mobile platform
Focus: Laser adjustment of height with variable camera focusing
Analytical method: Energy Dispersive X-ray Fluorescence Analysis Method combining FP and EC Methods
Security : Dual safety protection facilities:anti-collision laser detector and sensor detecting sample chamber cover opening and closing; There is no radiation in standby mode, the radiation level during operation is far lower than the international safety standard, and it is equipped with software interlocking device.
Dimensions: 485(W)×588(D)×505(H)mm
Sample chamber dimensions: 430(W)×400(D)×140(H)mm
Ambient temperature and humidity: 15℃~30℃,≤70%
Operating power supply: AC 220V±5V, it is recommended to configure AC purified regulated power supply
Instrument weight: 60kg
