Spesifikasi:
Circuit type: All solid-state RF power supply Input power supply: 220V, 30A
Operating Frequency: 27.12MHz
Frequency Stability: <0.01%
Output power: 800W~1500W
Output power stability: ≤0.01%
light path: Middle step grating+prism cross dispersion type
Focal length: 440mm
Grating specifications: Echelle grating
Wavelength range: 175nm~870nm
Nitrogen purge: High speed blowing 6L/min, normal blowing 2L/min
Detection wavelength range: l65nm ~ 900nm
Quantum efficiency: >30%@200nm
Refrigeration temperature: -45℃
Nitrogen purging flow rate: 3L/min
Wavelength range: 175nm~900nm
Repeatability: Relative standard deviation RSD < l.5 %
Stability: Relative standard deviation RSD < l.0 %
