Spesifikasi:
Power: 220~240VAC50/60Hz20A
Working environment temperature: 0~40℃
Relative humidity for working environment: 15~80%RH
Microwave source: 2450MHz; Maximun microwave output power 2000W, emitted from Dual magnetron inverter high-energy microwave field; non-pulse continuous microwave output
Installed power: 3800W
Microwave cavity: Grade 316L stainless steel microwave resonant cavity, with a wall thickness of more than 3mm, sprayed with multi-layer PFA coating
Furnace exhaust system : Automatically adjusted air volume; cooling to room temperature in less than 15 minutes
Software system: Android operating system (8G memory), built-in video SOP, application method library, electronic door lock, etc.
Overall physical size/net weight: 600×685×660 (W*D*H) /62kg
Batch amount: 24 vessels 40 vessels
Inner vessel material: TFM TFM
Outer vessel material: Aerospace composite fiber Aerospace composite fiber with TEFLON coating
Inner vessel volume: 110mL 55mL/70mL
Maximum temperature: 300℃ 300℃
Maximum pressure: 15Mpa 15Mpa
