O2 measurement : 0 to 21 Vol. %
CO measurement (H2 compensated) : 0 to 10.000 ppm
CO low measurement (H2 compensated) : 0 to 500 ppm
NO measurement : 0 to 4.000 ppm
NO low measurement : 0 to 300 ppm
NO2 measurement* : 0 to 500 ppm
SO2 measurement* : 0 to 5.000 ppm
Draught measurement : -40 to +40 hPa
Differential pressure measurement : -200 to 200 hPa
Absolute pressure measurement : 600 to +1.150 hPa
Derived parameters :
Efficiency : 0 to 120 %
Flue gas loss : 0 to 99.9 %
Exhaust gas dewpoint : 0 to 99.9 °C
CO2 measurement (Calculated from O2) : 0 to CO2 max.
Storage temperature : -20 to +50 °C
Operating temperature : -5 to +50 °C
Power supply : Battery block 3.7 V / 2.4 Ah & Mains unit 6.3 V / 2 A
Weight : 960 g
Housing material : TPE PC
Protection class : IP40
Dimensions : 283 x 103 x 65 mm
