IR Resolution: 256 × 192 (49, 152 pixels)
SuperIR : Yes, on captured images and live view
NETD : < 40 mK (@ 25 °C, F#=1.0)
Image Frequency : 25 Hz
Detector Pitch : 12 μm
Spectral Range : 7.5 to 14 μm
Focal Length : 3.5 mm
F-number : F1.1
Field of View (FOV) : 50° × 37.2°
Spatial Resolution (IFOV) : 3.43 mrad
Min. Focus Distance : 0.3 m (0.98 ft)
Focus Mode : Focus Free
Visual Camera : 3264 × 2448 (8 MP)
Display : 640 × 480 Resolution, 3.5" LCD Touch
Screen with auto-rotation Screen Brightness : Manual
Digital Zoom : 1.0x to 4.0x continuous
Color Palettes : White Hot, Black Hot, Rainbow, Ironbow, Red Hot, Fusion, Rain, Blue Red
Image Modes : Thermal/Visual/Fusion/PIP/Blending
Object Temperature Range : -20°C to 400°C ( -4°F to 752°F )
Accuracy Max : (±2°C/3.6°F, ±2%), for the ambient temp. 15°C to 35°C (59°F to 95°F) and object temp. above 0°C (32°F) Measurement Tools ; Center Spot, Hot Spot, Cold Spot
Level and Span Mode : Auto/Manual/1-Tap Touch-screen
Storage Media : Built-in 16 GB flash memory (user available storage space is less than the nominal capacity)
Image Storage Capacity : Approx. 60,000 Images
Image File Format : Radiometric JPEG
Annotations : Text note: max. 255 characters
Video Storage Capacity : Approx. 54 hours
Video File Format : MP4 video (25 Hz) and Radiometric video (5 Hz)
Radiometric Infrared-Video Streaming (Compressed) : Over UVC
Wi-Fi : 802.11 b/g/n (2.4 GHz and 5 GHz)
Bluetooth : Bluetooth 4.2, supports wireless headsets
USB Interface : USB Type-C
LED Light : Yes
Power Supply : USB-C (5V/2A)
Power Saving Mode : Auto Power-off and manual sleep
Battery Type : Rechargeable Li-ion battery
Battery Operating Time : Approx. 4 hours
Battery Charging Time : Approx. 2.5 hours fully charged
Protection Level : IP54
Drop Test Height : 2 m (6.56 ft)
Working Temperature Range : -10°C to 50°C (-4°F to 122°F)
Storage Temperature Range : -20°C to 60°C (-4°F to 140°F)
Relative Humidity : < 95% non-condensing
Weight : Approx. 218 g (0.481 lb)
Dimension : 138.5 × 85.2 × 23.6 mm (5.45 × 3.35 × 0.93 in)
Tripod Mounting : UNC ¼”-20
