IR Resolution: 256 × 192 (49,152 pixels)
NETD: < 40 mK (@ 25 °C, F#=1.0)
Image Frequency: 25 Hz
Detector Pitch: 12 μm
Spectral Range: 7.5 to 14 μm
Focal Length: 3.6 mm
F-number: F1.0
Field of View (FOV): 37.2° × 50.0°
Spatial Resolution (IFOV): 3.3 mrad
Focus Mode: Focus Free
Min. Focus Distance: 0.3 m (0.98 ft)
Visual Camera: 1600 × 1200 (2 MP)
Display: 240 × 320 Resolution, 3.2”LCD Screen
Image Modes: Thermal/Visual/Fusion/PIP
Color Palettes: Basic ,Black Hot, White Hot,Fire Detection,Rescue,Hot Area,Cold Area,Building
Color Alarm: Above alarm
USB Interface: USB Type-C
Battery Operating Time: Approx. 6 hours
Battery Type: Rechargeable Li-ion battery
Battery Charging Time: Approx. 3 hours fully charged
Protection Level: IP65
Working Temperature Range: Up to 10 minutes for ambient temperature -10°C to 90°C (14°F to 194°F); up to 2 minutes for ambient temperature -10°C to 115°C (14°F to 239°F)
Drop Test Height: 2 m (6.56 ft)
Storage Temperature Range: -20°C to 60°C (-4°F to 140°F)
Relative Humidity: < 95% non-condensing
Weight: Approx. 380 g (0.84 lb)
Dimension: 221.7 × 73.5 × 123.8mm (8.73 × 2.89 × 4.87 in)
Tripod Mounting: UNC ¼”-20
LED Light: Yes
