IR Resolution: 384 x 288 (110,592 pixels)
NETD: < 30 mK (@ 25°C, F#=1.0)
Image Frequency: 60 Hz
Detector Pitch: 17 μm
Spectral Range: 7.5 to 14 μm
Focal Length: 7 mm
F-number: F1.6
Field of View (FOV): 54.1°×40.2°
Spatial Resolution (IFOV): 2.42 mrad
Focus Mode: Focus Free
Image Sensor: VOx Uncooled Focal Plane Arrays, Germanium protective lens cover
Min. Focus Distance: 1 m (3.28 ft)
USB Interface: USB Type-C
Battery Type: Interchangeable and rechargeable Li-ion battery
Battery Operating Time: Approx. 6 hours
Battery Charging Time: Approx. 3 hours fully charged
Protection Level: IP67, IEC 60529
Drop Test Height: 2 m (6.56 ft), IEC 60068-2-31
Safety: IEC 61010-1
EMC: EN 301 489-1, EN 301 489-17, EN IEC 61000-6-2, EN IEC 61000-6-3
Vibration: 25 g, IEC 60068-2-27
Working Temperature Range: -20°C to 85°C (-4°F to 185°F)
150°C(302°F)，15min
260°C(500°F)，5min
Storage Temperature Range: -20°C to 60°C (-4°F to 140°F)
Relative Humidity: < 95% non-condensing
Weight: Approx. 1022g (2.25 lb)
Dimension: 132.7×276.3×114.6 mm (5.2 × 10.9 × 4.5 in)
Tripod Mounting: UNC ¼”-20
