IR Resolution: 480 × 360 (172,800 pixels)
SuperIR: 960 x 720 (691,200 pixels)
NETD: < 30 mK (@ 30 °C, F#=1.0)
Image Frequency: 30 Hz
Storage Media: Removable 128 GB SD Card
Image Storage Capacity: Approx. 120,000 Images
Annotations: Voice note: max. 60 seconds; Text note: max. 200 characters
Video Storage Capacity: Approx. 500 hours
Video File Format: MP4 video and radiometric video
Image Format: Radiometric JPEG
Radiometric Infrared-Video Streaming (Compressed): Over UVC, Wi-Fi
Wi-Fi: 802.11 b/g/n (2.4 GHz and 5 GHz)
Bluetooth: Bluetooth 4.2
USB Interface: USB Type-C
HDMI Interface: HDMI-D
Laser Pointer: Yes
Laser Pointer: Yes
HDMI Interface: HDMI-D
Laser: Yes, Class II, Wavelength: 635 nm; Power: < 1 mW
LED Light: Yes
Laser Distance Meter: Indoor distance: 50 m (164 ft); Outdoor distance: 10 m (33 ft).
GPS & Compass: Yes
Laser: Yes, Class II, Wavelength: 635 nm; Power: < 1 mW
Battery Type: Interchangeable and rechargeable Li-ion battery
LED Light: Yes
Battery Operating Time: Approx. 4 hours
Battery Type: Interchangeable and rechargeable Li-ion battery
GPS & Compass: Yes
Battery Charging Time: Approx. 2.5 hours fully charged
Battery Operating Time: Approx. 4 hours
Power Saving Mode: Yes
Battery Charging Time: Approx. 2.5 hours fully charged
Programmable Buttons: 2
Power Saving Mode: Yes
Protection Level: IP54, IEC 60529
Programmable Buttons: 2
Drop Test Height: 1 m (3.28 ft), IEC 60068-2-31
Protection Level: IP54, IEC 60529
Safety: IEC 61010-1
Drop Test Height: 1 m (3.28 ft), IEC 60068-2-31
EMC: EN 301 489-1, EN 301 489-17, EN IEC 61000-6-2, EN IEC 61000-6-4, EN 61326-1
Safety: IEC 61010-1
EMC: EN 301 489-1, EN 301 489-17, EN IEC 61000-6-2, EN IEC 61000-6-4, EN 61326-1
Vibration: 2 g, IEC 60068-2-6
Shock: 25 g, IEC 60068-2-27
Vibration: 2 g, IEC 60068-2-6
Shock: 25 g, IEC 60068-2-27
Working Temperature Range: -20°C to 50°C ( -4°F to 122 °F)
Storage Temperature Range: -20°C to 60°C ( -4°F to 140°F)
Working Temperature Range: -20°C to 50°C ( -4°F to 122 °F)
Relative Humidity: < 95% non-condensing
Storage Temperature Range: -20°C to 60°C ( -4°F to 140°F)
Relative Humidity: < 95% non-condensing
Weight: Approx. 1481 g (3.27 lb)
Weight: Approx. 1481 g (3.27 lb)
Dimension: 204.7 × 153.6 × 87.8 mm (8.06 × 6.05 × 3.45 in)
Tripod Mounting: UNC ¼”-20
Dimension: 210.1 × 141.03 × 87.8 mm (8.27 × 5.55 × 3.45 in)
LED Light: Yes
Tripod Mounting: UNC ¼”-20
Warranty: 3 years for the full product, 10 years for the detector, and 2 years for the battery.
LED Light: Yes
