IR Resolution : 256 × 192 (49,152 pixels)
SuperIR : Yes, on captured thermal images
NETD : < 40 mK (@ 25 °C, F#=1.0)
Image Frequency : 25 Hz
Detector Pitch : 12 μm
Spectral Range : 7.5 to 14 μm
Focal Length : 3.6 mm
F-number : F1.0
Field of View (FOV) : 37.2° × 50.0°
Spatial Resolution (IFOV) : 3.3 mrad
Min. Focus Distance : 0.3 m (0.98 ft)
Focus Mode: Focus Free
Display : 240 × 320 Resolution, 3.2”LCD Screen
Color Palettes : White Hot, Black Hot, Rainbow, Ironbow
Color Alarm : Above alarm
Image Modes : Thermal
Object Temperature Range : -20°C to 550°C (-4°F to 1022°F)
Accuracy : Max. (± 2°C/3.6°F, ± 2%), for ambient temperature 15°C to 35°C (59°F to 95°F) and object temperature above 0°C (32°F)
Measurement Tools : Center Spot, Hot Spot, Cold Spot User-definable: 3 spots
Level and Span Mode : Auto/Manual
Storage Media : Built-in 16 GB flash memory
Image Storage Capacity : Approx. 90,000 Images
Wi-Fi : 802.11 b/g/n (2.4 GHz)
USB Interface USB : Type-C
Battery Type : Rechargeable Li-ion battery
Battery Operating Time : Approx. 6 hours
Battery Charging Time : Approx. 3 hours fully charged
Protection Level: IP54
Drop Test Height: 2 m (6.56 ft)
Working Temperature Range : -10°C to 50°C (14°F to 122°F)
Storage Temperature Range : -20°C to 60°C (-4°F to 140°F)
Relative Humidity : < 95% non-condensing
Weight : Approx. 380 g (0.84 lb)
Dimension : 221.7 mm × 73.5 mm × 123.8 mm (8.73’’ × 2.89’’ × 4.87’’)
Tripod Mounting : UNC ¼”-20
