IR Resolution : 480 × 360 (172,800 pixels)
SuperIR : 960 × 720 (691,200 pixels)
NETD : < 35 mK (@ 25°C, F# = 1.0)
Image Frequency : 50 Hz
Detector Pitch : 17 μm
Spectral Range : 7.5 μm to 14 μm
Focal Length : 25 mm
F-number : F1.0
Field of View (FOV) : 18.7° × 14°
Spatial Resolution (IFOV) : 0.68 mrad
Min. Focus Distance : 0.3 m (0.98 ft)
Focus Mode : Laser Assisted AF/Continuous AF/AF/Manual Focus/Touch AF
Focus Speed : Approx. 2 second
Visual Camera : 3264 × 2448 (8 MP)
Display : 800 × 480 Resolution, 4.3" LCD Touch Screen
Screen Brightness : Manual/Auto
Digital Zoom : 1.x to 8.x continuous
Color Palettes : White Hot, Black Hot, Rainbow, Ironbow, Red Hot, Fusion, Rain, Blue Red
Focus Mode Palette : Above/Below/Interval
Color Alarm : Above/Below/Interval/Insulation/Condensation
Image Modes : Infrared/Visual/Fusion/PIP/Blending Object Temperature Range : -20 °C to 650 °C (-4 °F to 1202 °F)
Accuracy : Max (±2°C/3.6°F, ±2%)
Measurement Tools : Center Spot, Hot Spot, Cold Spot User-definable: Delta T, 10 spots, 1 line, 5 rectangles, and 5 circle
Level and Span Mode : Auto/Manual/1-Tap Touch-screen
Inspection Route : Yes
Storage Media : Removable 64 GB Micro SD Card
Image Storage Capacity : Approx. 60,000 Images
Annotations : Voice note: max. 60 seconds; Text note: max. 200 characters
Video Storage Capacity : Approx. 54 hours
Video File Format : MP4 video and radiometric video
Image Format : Radiometric JPEG
Radiometric Infrared-Video Streaming (Compressed) : Over UVC, Wi-Fi
Wi-Fi : 802.11 b/g/n (2.4 GHz and 5 GHz)
Bluetooth : Bluetooth 4.2
USB Interface : USB Type-C
HDMI Interface : Yes
LED Light : Yes
Laser Pointer : Yes
Laser Distance Meter : Indoor distance: 50 m (164 ft); Outdoor distance: 10 m (33 ft).
Laser : Yes, Class II, Wavelength: 635 nm; Power: < 1 mW
GPS ＆ Compass : Yes
Battery Type : Interchangeable and rechargeable Li-ion battery
Battery Operating Time : Approx. 4 hours
Battery Charging Time : Approx. 4 hours fully charged
Power Saving Mode : Yes
Protection Level : IP54, IEC 60529
Drop Test Height : 2 m (6.56 ft), IEC 60068-2-31
Safety : IEC 61010-1
EMC : EN 301 489-1, EN 301 489-17, EN IEC 61000-6-2, EN IEC 61000-6-3, EN IEC 61326-1, EN IEC 61326-2-2
Vibration : 2 g, IEC 60068-2-6
Shock : 25 g, IEC 60068-2-27
Storage Temperature Range : -20°C to 60°C ( -4°F to 140°F)
Working Temperature Range : -20°C to 50°C ( -4°F to 122°F)
Relative Humidity : < 95% non-condensing
Weight : Approx. 1058 g (2.33 lb)
Dimension : 284.7 × 120.6 × 124.5 mm (11.21 × 4.75 × 4.9 in)
Tripod Mounting : UNC ¼”-20
Wi-Fi : 802.11 b/g/n (2.4 GHz and 5 GHz)
