IR Resolution : 192 x 144 (27,648 pixels)
NETD : < 40 mK (@ 25 °C, F#=1.0)
Image Frequency : 25 Hz
Detector Pitch : 12 µm
Spectral Range : 7.5 to 14 µm
Focal Length : 6.9 mm
F-number : F1.0
Field of View (FOV) : 18.8° x 14.1°
Spatial Resolution (IFOV) : 1.74 mrad
Focus Mode : Manual Focus
Min. Focus Distance : 0.1 m (0.33 ft)
Visual Camera : 3264 x 2448 (8 MP)
Display : 640 x 480 Resolution, 3.5" LCD Touch Screen
Screen Brightness : Manual
Digital Zoom : 1.0x to 8.0x continuous
Image Modes : Thermal/Visual/Fusion/PIP/Blending
Color Palettes : White Hot, Black Hot, Rainbow, Ironbow, Red Hot, Fusion, Rain, Blue Red
Object Temperature Range : -20 °C to 550 °C (-4 °F to 1022 °F)
Accuracy : Max (±2°C/3.6°F, ±2%), for the ambient temp. 15°C to 35°C (59°F to 95°F) and object temp. above 0°C (32°F)
Measurement Tools : Center Spot, Hot Spot, Cold Spot User-definable: 10 spots, 1 line, and 3 rectangles
Level and Span Mode : Auto/Manual/1-Tap Touch-screen
Storage Media : Removable 16 GB Micro SD Card
Image Storage Capacity : Approx. 60,000 Images
Annotations : Voice note: max. 60 seconds; Text note: max. 200 characters
Video Storage Capacity : Approx. 15 hours
Video File Format : MP4 video
Wi-Fi : 802.11 b/g/n (2.4 GHz and 5 GHz)
Bluetooth : Bluetooth 4.2
USB Interface : USB Type-C
LED Light : Yes
Laser : Yes, Class II, Wavelength: 635 nm; Power: < 1 mW
Battery Type : Interchangeable and rechargeable Li-ion battery
Battery Operating Time : Approx. 6 hours
Battery Charging Time : Approx. 4 hours fully charged
Protection level : IP54
Drop Test Height : 2 m (6.56 ft)
Safety : IEC 61010-1
EMC : EN 50130-4, EN 55032, EN IEC 61000-3-2, EN 61000-3-3
Vibration : 1 g, IEC 60068-2-6
Shock : 15 g, IEC 60068-2-27
Working Temperature Range : -10°C to 50°C (-4°F to 122°F)
Storage Temperature Range : -20°C to 70°C (-4°F to 158°F)
Relative Humidity : < 95% non-condensing
Weight : Approx. 660g (1.46 lb)
Dimension : 244 x 100 x 104 mm (9.6 x 3.9 x 4.1 in)
Tripod Mounting : UNC ¼"-20
