IR Resolution : 192 × 144 (27,648 pixels)
NETD : <40 mK (@ 25°C, F#=1.0) Image Frequency : 25 Hz
Detector Pitch : 12 μm
Spectral Range : 7.5 μm to 14 μm
Focal Length : 3.6 mm
F-number : F1.0
Field of View (FOV) : 37.2°× 27.8° (H × V)
Spatial Resolution (IFOV) : 3.33 mrad Min. Focus Distance 0.5 m (1.64 ft)
Focus Mode : Focus Free
Visual Camera : 3264 × 2448 (8 MP)
Display : 640 × 480 Resolution, 3.5" LCD Touch Screen
Screen : Brightness Manual
Digital Zoom : 1.0× to 8.0× continuous
Color Palettes : White Hot, Black Hot, Rainbow, Ironbow, Red Hot, Fusion, Rain, Blue Red
Focus Mode Palette : N/A
Color Alarm : N/A
Image Modes : Thermal/Visual/Fusion/PIP/Blending
Object Temperature Range : -20°C to 550°C (-4°F to 1022°F)
Accuracy : Max (± 2°C/3.6°F, ± 2%), for the ambient temp. 15°C to 35°C (59°F to 95°F) and object temp. above 0°C (32°F)
Measurement Tools : Center Spot, Hot Spot, Cold Spot User-definable: 10 spots, 1 line and 3 rectangles.
Level and Span Mode : Auto/Manual/1-Tap Touch-scree
Storage Media : Removable 16 GB Micro SD Card
Image Storage Capacity : Approx. 60,000 Images
Annotations : Voice note: Max. 60 seconds; Text note: Max. 200 characters
Video Storage Capacity : Approx. 15 hours
Video File Format : MP4 video
Wi-Fi : 802.11 b/g/n (2.4 GHz and 5 GHz)
Bluetooth : Bluetooth 4.2
USB Interface : USB Type-C
LED Light : Yes Laser Yes, Class II, Wavelength: 635 nm; Power: < 1 mW
Battery Type : Interchangeable and rechargeable Li-ion battery
Battery Operating Time : Approx. 6 hours
Battery Charging Time : Approx. 4 hours fully charged
Protection Level IP54
Drop Test Height 2 m (6.56 ft)
Safety : IEC 61010-1
EMC : EN 50130-4, EN 55032, EN IEC 61000-3-2, EN 61000-3-3
Vibration : 1 g, IEC 60068-2-6 Shock 15 g, IEC 60068-2-27
Working Temperature Range : -10°C to 50°C (-4°F to 122°F)
Storage Temperature Range : -20°C to 70°C (-4°F to 158°F)
Relative Humidity : < 95% non-condensing
Weight : Approx. 660 g (1.46 lb)
Dimension : 244 mm × 100 mm × 104 mm (9.6" × 3.9" × 4.1")
Tripod Mounting : UNC ¼”-20
