IR Resolution : 640 x 480 (307,200 pixels)
SuperIR : 1280 x 960 (1,228,800 pixels)
NETD : < 35 mK (@ 25°C, F#=1.0)
Image Frequency : 25 Hz
Detector Pitch : 17 μm
Spectral Range : 7.5 to 14 μm
Focal Length : 15 mm
F-number : F1.0
Field of View (FOV) : 41.9° × 33.3°
Spatial Resolution (IFOV) : 1.13 mrad
Min. Focus Distance : 0.3 m (0.98 ft)
Focus Mode : Manual Focus
Visual Camera : 3264 × 2448 (8 MP)
Display : 640 × 480 Resolution, 3.5" LCD Touch Screen
Screen Brightness : Manual
Digital Zoom : 1.0x to 8.0x continuous
Color Palettes : White Hot, Black Hot, Rainbow, Ironbow, Red Hot, Fusion, Rain, Blue Red
Focus Mode Palette : Above/Below/Interval
Color Alarm : Above/Below/Interval/Insulation
Image Modes : Thermal/Visual/Fusion/PIP/Blending
Object Temperature Range : -20°C to 650°C (-4°F to 1202°F)
Accuracy : Max (±2°C/3.6°F, ±2%)
Measurement Tools : Center Spot, Hot Spot, Cold Spot User-definable: 10 spots, 1 line, 5 rectangles, and 5 circles
Level and Span Mode : Auto/Manual/1-Tap Touch-screen
Storage Media : Removable 64 GB Micro SD Card
Image Storage Capacity : Approx. 35,000 Images
Annotations : Voice note: max. 60 seconds; Text note: max. 200 characters
Video Storage Capacity : Approx. 54 hours
Video File Format : MP4 video and radiometric video
Wi-Fi : 802.11 b/g/n (2.4 GHz and 5 GHz)
Bluetooth : Bluetooth 4.2
USB Interface : USB Type-C
LED Light : Yes
Laser : Yes, Class II, Wavelength: 650 nm; Power: < 1 mW
Battery Type : nterchangeable and rechargeable Li-ion battery
Battery Operating Time : Approx. 4 hours
Battery Charging Time : Approx. 4 hours fully charged
Power Saving Mode : No
Protection Level : IP54
Drop Test Height : 2 m (6.56 ft)
Safety : IEC 61010-1
EMC : EN55032, EN61326-1, EN61000-3-2,EN61000-3-3,EN IEC 61000-6-2, EN IEC 61000-6-3
Vibration : 0.03 g2/Hz (3.8 g), 2.5 g IEC 60068-2-6
Shock : 25 g, IEC 60068-2-27
Working Temperature Range : -20°C to 50°C ( -4°F to 122°F)
Relative Humidity : < 95% non-condensing
Storage Temperature Range : -20°C to 70°C (-4°F to 158°F)
Weight : Approx. 686 g (1.51 lb)
Dimension : 244 × 100 × 104 mm (9.6 × 3.9 × 4.1 in)
Tripod Mounting : UNC ¼”-20
