IR Resolution: 480 × 360 (172,800 pixels)
SuperIR: 960 x 720 (691,200 pixels)
NETD: < 30 mK (@ 30 °C, F#=1.0)
Image Frequency: 30 Hz
Storage Media : Removable 128 GB SD Card
Image Storage Capacity : Approx. 120,000 Images
Annotations : Voice note: max. 60 seconds; Text note: max. 200 characters
Video Storage Capacity : Approx. 500 hours
Video File Format : MP4 video and radiometric video
Image Format : Radiometric JPEG
Radiometric Infrared-Video Streaming (Compressed) : Over UVC, Wi-Fi
Wi-Fi : 802.11 b/g/n (2.4 GHz and 5 GHz)
Bluetooth : Bluetooth 4.2
USB Interface : USB Type-C
HDMI Interface : HDMI-D
Laser Pointer : Yes
Laser Pointer : Yes
HDMI Interface : HDMI-D
Laser : Yes, Class II, Wavelength: 635 nm; Power: < 1 mW
LED Light : Yes
Laser Distance Meter : Indoor distance: 50 m (164 ft); Outdoor distance: 10 m (33 ft).
GPS & Compass : Yes
Laser : Yes, Class II, Wavelength: 635 nm; Power: < 1 mW
Battery Type : Interchangeable and rechargeable Li-ion battery
LED Light : Yes
Battery Operating Time : Approx. 4 hours
Battery Type : Interchangeable and rechargeable Li-ion battery
GPS & Compass : Yes
Battery Charging Time : Approx. 2.5 hours fully charged
Battery Operating Time : Approx. 4 hours
Power Saving Mode : Yes
Battery Charging Time : Approx. 2.5 hours fully charged
Programmable Buttons : 2
Power Saving Mode : Yes
Protection Level : IP54, IEC 60529
Programmable Buttons : 2
Drop Test Height : 1 m (3.28 ft), IEC 60068-2-31
Protection Level : IP54, IEC 60529
Safety : IEC 61010-1
Drop Test Height : 1 m (3.28 ft), IEC 60068-2-31
EMC : EN 301 489-1, EN 301 489-17, EN IEC 61000-6-2, EN IEC 61000-6-4, EN 61326-1
Safety : IEC 61010-1
EMC : EN 301 489-1, EN 301 489-17, EN IEC 61000-6-2, EN IEC 61000-6-4, EN 61326-1
Vibration : 2 g, IEC 60068-2-6
Shock : 25 g, IEC 60068-2-27
Vibration : 2 g, IEC 60068-2-6
Shock : 25 g, IEC 60068-2-27
Working Temperature Range : -20°C to 50°C ( -4°F to 122 °F)
Storage Temperature Range : -20°C to 60°C ( -4°F to 140°F)
Working Temperature Range : -20°C to 50°C ( -4°F to 122 °F)
Relative Humidity : < 95% non-condensing
Storage Temperature Range : -20°C to 60°C ( -4°F to 140°F)
Relative Humidity : < 95% non-condensing
Weight : Approx. 1451 g (3.2 lb)
Weight : Approx. 1451 g (3.2 lb)
Dimension : 210.1 × 141.03 × 87.8 mm (8.27 × 5.55 × 3.45 in)
Tripod Mounting : UNC ¼”-20
Dimension : 210.1 × 141.03 × 87.8 mm (8.27 × 5.55 × 3.45 in)
LED Light : Yes
Tripod Mounting : UNC ¼”-20
Warranty : 3 years for the full product, 10 years for the detector, and 2 years for the battery.
LED Light : Yes
