Distance Measurement
Typical measuring tolerance : ±1.0 mm 3
Maximum measuring tolerance : ±2.0 mm 3
Range At Leica Target Plate GZM26 : 80 m / 260 ft
Typical range : 80 m / 260 ft
Range at unfavorable condition : 60 m / 195 ft
Smallest unit displayed : 6 / 30 / 60 mm (10 / 50 / 100 m)
Ø Laser point at distances : 6 / 30 / 60 mm (10 / 50 / 100 m)
Tilt Measurement
Measuring tolerance to laser beam : -
Measuring tolerance to housing : -
Range : -
Laser cass : 2
Laser type : 635 nm, < 1 mW
Protection class : IP54
Automatic laser off : After 90 seconds
Automatic power off : After 180 seconds
Size (L x W x D) : 127 x 56 x 33 mm
Weight (with batteries) : 153 g
