Measurement principle: Solvent extraction-non-dispersive infrared absorption analysis method
Measurement range: 0mg/L ~ 200mg/L
Resolution : 0 to 99.9 mg/L; 0.1 mg/L & 100 to 200 mg/L; 1 mg/L
Repeatability :
0 to 9.9 mg/L; ± 0.4 mg/L ± 1 digit
10.0 to 99.9 mg/L; ± 2 mg/L ± 1 digit
100 to 200 mg/L; ± 4 mg/L ± 1 digit
*For standard liquids
Display Method : 3.5 inches, 320×240 dots
Backlight Colour graphic LCD
Calibration Method : Select each optionally zero and span calibration
Extraction Solvent : S-316 solvent
※Do not use any other solvent than S-316
Amount of extraction solvent required : Approx. 6.5ml (Amount of extration solvent required)
Extraction Method
Using the extraction solvent and extracted manually outside the product
Ambient Operationg Temperature
0 to 40 ℃ (non condensation)
Power supply
AC 100V to 240V ±10%, 50/60 Hz
Power consumption
AC 100V to 240V : Approx.60VA
External Dimensions
195(H)×253(W)×293(D) mm
Mass
Approx. 5 kg
External Output
Output to an USB memory stick
