Spesifikasi:
Optical Unit: Containing the camera, coaxial reflected light, 10× optical-motorized zoom, and overview camera.
Objectives: Connected to the optical unit via a bayonet mount. They contain switchable ringlight and storage module in which the exact magnification is saved.
Stage: Powered by a stepper motor with integrated controller which makes it possible to move in a reproducible manner to relevant areas of the sample.
Stand: Powered by a motorized z-drive for focusing and a swing arm to adjust the viewing angle in relation to the surface of the sample. In addition, the stand contains a second
motorized drive to correctly adjust the pivot point in relation to the sample height.
Controller: Comprising a dual rotary wheel for controlling zoom, focus, and stage movement; a touch pad for gesture controlling hardware and software; touch display for operating
software features; and detachable wireless keyboard.
All-in-One PC: Containing the Smartzoom 5 application software and connected to the controller via USB 2 and to the stand via USB 3
Maximum Resolution: ~ 0.56 µm
Maximum Magnification: 2,020× (with respect to a 17.5" display diagonal and an aspect ratio of 4:3)
FWD at Maximum Magnification: 10 mm
FOV at Minimum Magnification: 39 mm
Camera:
Sensor type: CMOS
Sensor size: 1", 4.2 megapixel
Effective sensor diagonal: 11 mm
Pixel size: 5.5 µm
Total pixels: 2,048 × 2,048
Available pixels: 1,920 × 1,440
Effective pixels: 1,600 × 1,200
Image Resolution:
Standard: 2 megapixel
True RGB: 2 megapixel
High definition: 18 megapixel
Image Format : .czi
Export: .czi, .jpg, .tif, .png
Frame Rate Live Image: Up to 30 fps Optical Zoom: Zoom factor: 10×
Zoom range: 0.5× to 5.0×
Objectives: PlanApo D 0.5×/0.03 (FWD 78 mm); PlanApo D 1.6×/0.1 (FWD 36 mm); PlanApo D 5.0×/0.3 (FWD 30 mm); PlanApo D 10.0×/0.6 (FWD 10 mm)
